Baltic delivers API 6A ball valves & choke valves to the U.K customer

Baltic delivers API 6A ball valves & choke valves to the U.K customer

  • 07 25, 2018
We have got a purchase order from one of our U.K. customers; the project is in Iraq.
The detailed products are as the following.

Description:
API 594 DUAL- PLATE CHECK VALVE
Wafer, through drilled LUG, horizontal or vertical installation, with FLOW direction

Material:
Body: ASTM A216 WCB
Disc: ASTM A351 CF8M
Shaft: ASTM A182 F316
Trim: 12#
Seat: Stellite
Spring: INCONEL X750
Connection: RTJ acc. to ASME B16,5
Face to Face: API 594 = 206mm
Other Request: NACE MR0175

Item 1)  20 PCS  size: 8 inch   class: 1500 LB

======================================================

API 600 GATE VALVE
With gearbox, OS&Y, BB, rising stem,
FULL bore, flexible wedge, with back seat

Material:
Body: ASTM A216 WCB
Trim: 12#
Stem: ASTM A182 F316 / 17-4PH
Wedge: WCB + AISI 316 (Overlay)
Body Seat: A105 + Stellite
Stud/Nut: A193 B7M/ A194 2HM
Stem Packing: Graphite + SS 316
Bonnet Gasket: RTJ Ring - SS 304

Connection: RTJ acc. to ASME B16,5
Face to Face: ASME B16.10 = 841mm
Other Request: NACE MR0175

Item 2)  20 PCS  size: 8 inch   class: 1500 LB

======================================================

API 6A BALL VALVE
With gearbox, metal seat
3PC body, Trunnion Mounted, solid ball, full bore
Fire safe design, antistatic device, blow out proof stem

Material:
Body: 4130
Ball: F6A+Tungsten Carbon Coated
Stem: ASTM A479 Gr. XM-19
Seat: F6A+Tungsten Carbon Coated
Flexible Graphite Seal
Stud/Nut：A193 B7M/ A194 2HM
Spring: INCONEL X750

Connection: RTJ acc. to ASME B16,5
Face to Face: ASME B16.10
Other Request: NACE MR0175

Item 3)  12 PCS  size: 3-1/8 inch   class: 3000 PSI

======================================================

API 6A CHOKE VALVE
With hand wheel + indicator to be marked 1/64”
H2 TYPE, MAX 3" ORIFICE, R37,
NEEDLE, RIGHT ANGLE PR2, Bolted Bonnet

Material:
Body: 4130
Trim: F6A+Tungsten Carbon Coated
Stem: ASTM A479 Gr. XM-19
Stud/Nut: A193 B7M/ A194 2HM
Gasket: Soft Iron

Connection: RTJ acc. to ASME B16,5
Face to Face: ASME B16.10
Other Request: NACE MR0175

Item 4)  15 PCS  size: 4-1/16 inch   class: 3000 PSI

======================================================

API 6D BALL VALVE
With gearbox, Metal Seat
3PC body, Trunnion Mounted, Solid Ball, Full Bore,
Fire Safe Design, Anti-Static Device Blow Out Proof Stem

Material:
Body: A105N
Ball: F316+Tungsten Carbon Coated
Stem: ASTM A479 Gr. XM-19
Seat: F316+Tungsten Carbon Coated
Flexible Graphite Seal
Stud/Nut: A193 B7M/ A194 2HM

Connection: RTJ acc. to ASME B16,5
Face to Face: ASME B16.10 = 711mm
Other Request: NACE MR0175

Item 5)  10 PCS  size: 6 inch   class: 1500 LB
======================================================
