GS-C25 Wedge Gate Valve, DN300, PN100, EN 1984, DIN 3352

Key Specifications / Features

Model No.: Hits: 112

GS-C25 Wedge Gate Valve Provider: EN 1984 GS-C25 Gate Valves, DIN 3352, DN300, PN100, RF Ends, Gearbox Operation, FF EN 558-1/line 26, Test EN 12266-1.

Request a quote Share

Tags:

Next: Flexible Wedge Gate Valve, 3 Inch, 150 LB, WCB, API 600

Previous: API 600 flexible Wedge Gate Valve, A216 WCB Body, 30 Inch, 300 LB

Detail Information

Valve Description
Product Name: Flexible Wedge Gate Valve
Design: EN 1984, DIN 3352
Material: GS-C25
Nominal Size: DN300
Nominal Pressure: PN100
Connection Ends: RF X RF, as per EN 1092-1/B2
Face to Face: EN 558-1/line 26
Model of Operation: Gearbox
Test and Inspection: EN 12266-1

Technical Parameters and Characteristics
Product Type: Gate Valve.
Size Range: NPS 2 - 60 Inch, DN50 - DN1500.
Design Pressure: Class 150 - 2500 LB, PN10 - PN420.
Design Standard: API 600, ASME B16.34, EN 1984, DIN 3352.
Design Temp.: -196℃ - 573℃.
Material: ASTM A216 WCB, ASTM A216 WCC, ASTM A217 WC6, ASTM A217 WC9, ASTM A217 C5, ASTM A217 C12A, ASTM A352 LCB, ASTM A352 LCC, ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3M, ASTM A351 CF8C, CN3MN, CK3MCUN, CN7M, ASTM A890 4A (CD3MN), ASTM A890 5A (CE3MN), ASTM A890 6A (CD3MWCuN), ASTM B148 C95800, ASTM B148 C95500.
Connection End: ASME B16.5, ASME B16.25, EN1092 series.
Operation: Handwheel, gearbox, electric.
Application: Electric power, petroleum refining, petrochemical engineering, offshore oil, chemical engineering.
