ASTM A182 F316 Threaded Ball Valve, 1/2 IN, 800 LB, API 608

Looking for a reliable threaded ball valve provider? Look no further than our selection of ASTM A182 F316 valves. Our 1/2 inch, 800 LB valves feature a DN15 and PN130 rating, as well as a two-piece body and side entry design. Compliant with API 608 standards and featuring F-NPT threading as per ASME B1.20.1, these valves are the perfect solution for a wide range of industrial applications. Trust us to provide the high-quality valves you need to get the job done right.

Tags:

• ASTM A182 F316 Ball Valve
• 1/2 Inch Ball Valve
• Class 800 LB Ball Valve
• API 608 Ball Valve
• DN15 Ball Valve
• PN130 Ball Valve
• 2PC Ball Valve
• Side Entry Ball Valve
• NPT Ball Valve

Side entry threaded ball valve, 2-PC body, NPS 1/2, 800 LB, F316, NPT.

Valve description:
Ball valve with Hand Lever.
Design: API 608.
Body: ASTM A182 F316.
Nominal size: 1/2 inch.
Nominal class: 800 lbs.
End Connection: F-NPT as per ASME B1.20.1.
Face to face: as per MFG STD.
Test and inspection: API 598.

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: NPT, SW, BW, Flanged.
Pressure range: Class 150 - 1500 LB (PN16 - PN250).
Working temperature: -46℃ - +200℃.
