• ASTM A182 F316 Globe Valve, 1/2 Inch, 300 LB, RF, API 602
ASTM A182 F316 Globe Valve, 1/2 Inch, 300 LB, RF, API 602

ASTM A182 F316 Globe Valve, 1/2 Inch, 300 LB, RF, API 602

ASTM A182 F316 Globe Valve, 1/2 Inch, 300 LB, RF, API 602

Key Specifications / Features

Model No.: Hits: 13

Looking for a reliable supplier of ASTM A182 F316 Globe Valves? Look no further! Our offerings include 1/2 Inch valves, DN15 size, Class 300 LB and PN50 pressure ratings, conforming to API 602 standards with RF End connections. Perfect for applications in Power Stations, Petroleum, and Chemical Engineering industries. Trust us for quality and performance.
Request a quote Share

Next: ASTM A105N Globe Valve, 3 Inch, 300 LB, API 602, RF

Previous: Globe Valve with Regulating Disc, A105N, 1.5IN, CL600, API 602, RF

Detail Information

Valve description:
Name: Small size globe valve, with integral flange.
Design: API 602.
Body: ASTM A182 F316.
Nominal size: 1/2 Inch.
Nominal class: 300 LB.
End connection: RF.
Face to face: ASME B16.10.
Test and inspection: API 598.

Technical parameters and characteristics
Product Small-size globe valve
Nominal diameter 1/4 - 4 Inch
Design temp.  -196℃ - 573℃
Design pressure Class 150 - 4500  LB
Material Forged carbon steel, Stainless steel, Alloy steel, Bronze
Design standard API 602, BS 5352
Face to face Manufacture standard, ASME B16.10
Connection end NPT, SW, BW, Flange
Test standard API 598, ISO 5208
Operation Hand wheel, electric
Application Power station, petroleum, chemical engineering
Function 1 bolted bonnet, welded bonnet, pressure seal bonnet
Function 2 plug disc, needle disc
Function 3 full bore, reduced bore
Function 4 Integral flanged ends、welded on flanged ends
