ASME B16.34 Double Block Bleed Ball Valve, 2 Inch, 600 LB

Buy ASME B16.34 double block and bleed ball valve from a trusted supplier. Our valve is made of ASTM A350 LF2 material, measures 2 inches, and has a class rating of 600 LB. It is suitable for DN50 and PN100 applications and complies with EEMUA 182 standards. The valve is a one-piece design and features RF flanged connections.

Tags:

• ASME B16.34 Ball Valve
• 2 Inch Ball Valve
• Class 600 LB Ball Valve
• ASTM A350 LF2 Ball Valve
• DN50 Ball Valve
• PN100 Ball Valve
• EEMUA 182 Ball Valve
• RF Ball Valve

DBB ball valve, NPS 2, 600 LB, LF2, RF.

Valve description:
DBB ball valve (ball/needle/ball), with hand lever.
Design: EEMUA 182, ASME B16.34.
Body Pattern: one piece.
Body: ASTM A350 LF2.
Nominal size: 2 Inch.
Nominal class: 600 LB.
End Connection: RF Flanged.
Face to face: as per manufacturer's standard.
Test and inspection: EEMUA 182, API 598.
Operation: lever.

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal diameter: 1/2 - 24 Inch (DN15 - DN600).
End connection: Flanged x Flanged, Flanged X NPT.
Pressure range: Class 150 - 3000 LB, 15000 PSI.
Working temperature: -46℃ - +350℃.
